When buying a used excavator, bulldozer, or wheel loader, the biggest fear is being fooled by a beautifully presented inspection report. An inspection report can directly tell you the true condition of the equipment, but only if you know how to read it, ask the right questions, and cross-check it against the actual machine. Sanqi Machinery has been on the frontline of used construction machinery import and export for over a decade, and we can responsibly say: the data on the report is static, while the equipment is dynamic. True experts always bring the report to the site for a second inspection. Below, we thoroughly explain inspection items, report interpretation, and key on-site points.
What Does an Inspection Report Actually Check: Core Items and Quantitative Indicators
A qualified inspection report should cover at least the following major systems, each with specific numerical values or status descriptions, not just vague terms like 'good' or 'normal' to gloss over issues.
- Engine System: Includes whether cold start is smooth, any abnormal noises, exhaust smoke color (blue smoke indicates burning oil, black smoke indicates incomplete combustion), oil pressure values, and any leaks in the cooling system. Pay special attention to the hour meter and engine overhaul records; be extra cautious if hours exceed 15,000.
- Hydraulic System: Main pump pressure values (for excavators, typically around 34.3 MPa, varying by brand), hydraulic oil temperature rise rate, whether cylinders have internal leakage, and whether hoses are damaged or leaking. Hydraulic component replacement costs are high, and this part directly affects future investment.
- Undercarriage and Drive System: Track chain wear (if pitch elongation exceeds standard values, replacement is needed), whether drive sprocket teeth are sharp, swing bearing clearance, and whether gear shifting is smooth. For mining trucks, also measure braking distance and tire wear.
- Structural Components and Frame: Check for cracks or weld repairs on the boom, arm, bucket, and frame. Weld scars and original factory welds are clearly distinguishable under high-definition images. This is also where accident vehicles are most likely to be exposed.
- Electrical System: Check all lights, instruments, air conditioning, and sensors for proper operation, and inspect wiring harnesses for aging or unauthorized modifications—many minor issues stem from electrical problems.
Inspection reports typically list items as 'pass/fail', but a failed item doesn't necessarily mean the equipment is unbuyable. The key is to identify the problem and estimate repair costs.
How to Read the Report: The Real Meaning Behind the Data
When you get the report, first check whether the equipment model, year, and hours match the nameplate on the machine. Any discrepancy indicates a problem. Then review each item:
- Engine Power Test: If the report shows power output more than 10% below the rated value, it indicates severe engine wear that may not be fixed by simply adjusting the valves. For example, a CAT 320D with a rated power of 110 kW, if measured below 100 kW, should warrant a price reduction of at least 50,000 RMB.
- Hydraulic Flow and Pressure: Low values could indicate pump wear or valve block blockage, with repair costs easily reaching 20,000-30,000 RMB. If the report doesn't include these measurements, request an on-site test.
- Remaining Life of Wear Parts: For example, the four wheels and one belt (track rollers, carrier rollers, idlers, drive sprockets, and track), the report will give a wear percentage. If remaining life is below 20%, replacing with original parts can cost at least 50,000-60,000 RMB for cheaper ones, and more for imported parts.
- 'No Major Accidents' Statement: Check specifically whether non-destructive testing (NDT) was performed on the frame, boom, and arm. Many reports only state 'no obvious deformation' or 'no cracks found', but without NDT, it's meaningless.
Additionally, the inspection date on the report is crucial. Data from three months ago may differ significantly from the current condition, especially for issues like hydraulic oil leaks that can worsen quickly.
Five Steps for On-Site Inspection: Even with a Good Report, Verify by Hand
The report is static, but the equipment is dynamic. On-site inspection is the last line of defense. Sanqi Machinery recommends the following sequence:
- Cold Start Check: After sitting overnight, if the engine emits blue smoke or has difficulty starting in the morning, it's likely due to piston ring wear or valve seal aging. This is hard to detect after the engine is warm.
- Operate All Functions: Run each function through its full range of motion, feeling for any sticking, vibration, or abnormal noise. For example, when performing combined operations on an excavator (simultaneous swing, boom lift, and arm curl), if the speed noticeably slows down, the hydraulic pump may have internal leakage.
- Travel and Maneuvering Test: Drive the machine around a few laps to feel the travel power and listen for abnormal noises from the travel motors. If the tracks pull to one side, it could be an issue with the tension cylinder or idler.
- Post-Test Inspection: With the machine hot, check hydraulic oil temperature and level. When opening the oil filler cap, see if there's any spray or unusual odor. If the oil is dark and smells burnt, it's time for an oil change. Also check the engine oil pan and transmission for leaks.
- NDT on Critical Welds: For load-bearing areas like the boom root and frame pivot points, use an ultrasonic flaw detector to test. If the report didn't include this, it's worth paying a few hundred RMB for a supplementary test.
During on-site inspection, it's best to bring an experienced operator—one person operates while another observes, which is far more effective than watching videos yourself.
The Cost Beyond the Report: Repair and Parts Market
The inspection report reflects the current condition, but future investment is the bigger concern. Take a 20-ton used excavator as an example: the whole machine price is roughly 400,000-600,000 RMB (depending on condition and brand). An engine mid-overhaul (replacing pistons, liners, rings, and bearings) costs 20,000-40,000 RMB, hydraulic pump repair costs 10,000-30,000 RMB, and replacing a set of travel motors costs 10,000-20,000 RMB. Imported original parts are significantly more expensive than domestic ones, but they also last longer. Sanqi Machinery has long been involved in exporting used equipment, and many Southeast Asian customers value parts supply capability—asking about parts availability and cost before buying is more important than haggling over a few thousand RMB on the machine price.
Common Questions FAQ
Q: Can the hour meter reading on the inspection report be trusted?
A: Hour meters can be tampered with, but you can estimate by comparing wear on components. If track wear is inconsistent with the hour reading, it's suspicious.
Q: Are inspection standards the same for imported and domestic used construction machinery?
A: The basic items are the same, but for imported machines, you need to consider emission compliance and future parts procurement. It's advisable to have a company with import/export experience handle it.
Q: If the inspection report shows hydraulic oil seepage, can I still buy it?
A: Seepage varies in severity. Minor seepage may just require replacing a seal, while major leaks require disassembly and repair. Factor the repair cost into your offer.
Q: What procedures are required for exporting used excavators?
A: It mainly depends on the destination country's policies. Generally, you need export commodity inspection, customs declaration, and certificate of origin. It's recommended to use a company with export qualifications to handle it and avoid port delays.
Q: With a limited budget, can I buy equipment with major weld repairs?
A: If the welding is on non-critical parts and the workmanship is good, it might be considered if the price is low enough. However, never touch machines with repaired booms or frames—safety is not guaranteed.
